Description
BLUE SMART IP22 CHARGER 24/16:
Bluetooth Smart enabled – The Blue Smart IP22 Charger is the wireless solution to monitor voltage and current, to change settings, and to update the charger when new features become available. The highest efficiency ever! With up to 94% efficiency, these chargers generate up to four times less heat when compared to the industry standard. And once the battery is fully charged, power consumption reduces to 0,5 Watt, some five to ten times better than the industry standard. NIGHT and LOW setting – When in NIGHT or LOW mode, the output current is reduced to max. 25% of the nominal output and the charger will be noiseless. The NIGHT mode automatically ends after 8 hours. The LOW mode can be ended manually.
Victron Blue Smart Bluetooth 24-volt 16-amp three output battery charger with IP22 rating suitable for AGM, Gel and Lithium Ion battery charging.
| Model | BPC241644012 |
|---|---|
| Output Current Rating (Amps) | 16.0 Amps |
| Efficiency | 94% |
| Operating Temperature Range | -20 to +50°C |
| Humidity | Max 98% |
| Output | 3 |
| Output System Voltage | 24V |
| Charge current | 16 A |
| Dimensions | 108 x 65 x 235 mm (L x W x H) |
| Net Weight (kg) | 1.3 Kg |
| Charge Algorithm | 6-stage adaptive |
| Charge voltage ‘absorption’ | Normal: 28.8V | High: 29.4V | Li-ion: 28.4V |
| Charge Voltage Float – Wet (25 degrees)** | Normal: 27.6V | High: 27.6V | Li-ion: 27.0V |
| Charge voltage ‘storage’ | Normal: 26.4V | High: 26.4V | Li-ion: 27.0V |
| Protection | Battery reverse polarity (fuse), Output short circuit, and Over temperature |
| Charge current in low current mode | 8 A |
| No load power consumption | 0.5 W |
| Protection category | IP22 |
| Battery-connection | Screw terminals 13 mm² / AWG6 |
| Input Voltage | 180 – 265 VAC |
| Can be used as power supply | Yes |
| Manufacturers Warranty | 5 Years |
